SOVEREIGN 32

Sailboat Specifications

both US imperial metric

Hull Type:

Fin Keel

Rigging Type:

Cutter

LOA:

32.00 ft / 9.75 m

LWL:

25.00 ft / 7.62 m

Beam:

10.50 ft / 3.20 m

S.A. (reported):

533.00 ft² / 49.52 m²

Draft (max):

5.00 ft / 1.52 m

Displacement:

14,560 lb / 6,604 kg

Ballast:

6,496 lb / 2,947 kg

S.A./Disp.:

14.35

Bal./Disp.:

44.62

Disp./Len.:

416.00

Construction:

FG

First Built:

1971

Builder:

Sea Glass Ltd. (UK)

Designer:

Ian Anderson

Auxiliary Power/Tanks (orig. equip.)

Make:

Thornycroft

Type:

Diesel

HP:

35

Fuel:

30 gals / 114 L

Sailboat Calculations

Definitions

S.A./Disp.:

14.35

Bal./Disp.:

44.62

Disp./Len.:

416.00

Comfort Ratio:

36.23

Capsize Screening Formula:

1.72

Accommodations

Water:

70 gals / 265 L

Sailboat Links

Designers:

Ian Anderson

Builders:

Upham (UK) (J. W. and A. Upham Ltd.)

Download Boat Record:

PDF
