SWAN 68 (TRAD)

Sailboat Specifications

both US imperial metric

Hull Type:

Fin w/bulb & spade rudder

Rigging Type:

Masthead Sloop

LOA:

68.00 ft / 20.73 m

LWL:

54.72 ft / 16.68 m

Beam:

17.78 ft / 5.42 m

S.A. (reported):

2,164.00 ft² / 201.04 m²

Draft (max):

10.83 ft / 3.30 m

Displacement:

88,184 lb / 40,000 kg

Ballast:

35,274 lb / 16,000 kg

S.A./Disp.:

17.56

Bal./Disp.:

40.00

Disp./Len.:

240.27

Construction:

FG

First Built:

1992

Last Built:

2004

Builder:

Nautor

Designer:

German Frers

Sailboat Calculations

Definitions

S.A./Disp.:

17.56

Bal./Disp.:

40.00

Disp./Len.:

240.27

Comfort Ratio:

50.28

Capsize Screening Formula:

1.60

S#:

2.32

Rig and Sail Particulars

help

I:

90.00 ft / 27.43 m

J:

25.90 ft / 7.89 m

P:

81.50 ft / 24.84 m

E:

24.50 ft / 7.47 m

S.A. Fore:

1,165.50 ft² / 108.28 m²

S.A. Main:

998.38 ft² / 92.75 m²

S.A. Total (100% Fore + Main Triangles)

2,163.88 ft² / 201.03 m²

S.A./Disp. (calc.):

17.56

Est. Forestay Len.:

93.65 ft / 28.55 m

Sailboat Links

Designers:

German Frers

Builders:

Nautor (Swan sailboats)

Related Sailboats:

SWAN 68

Download Boat Record:

PDF

Notes

SWAN 68 with traditional counter.
See SWAN 68 for more details.
