Sailboat Specifications

Definitions
Hull Type: Long Keel
Rigging Type: Masthead Sloop
LOA: 34.94 ft / 10.65 m
LWL: 27.50 ft / 8.38 m
S.A. (reported): 540.00 ft² / 50.17 m²
Beam: 10.17 ft / 3.10 m
Displacement: 11,480.00 lb / 5,207 kg
Ballast: 5,290.00 lb / 2,400 kg
Max Draft: 5.17 ft / 1.58 m
Construction: FG
First Built: 1974
Builder: Vindö Marin AB (SWE)
Designer: Carl Andersson

Auxiliary Power/Tanks (orig. equip.)

Make: Volvo Penta
Model: MD3
Type: Diesel
HP: 36
Fuel: 30 gals / 114 L

Accomodations

Water: 50 gals / 189 L

Sailboat Calculations

Definitions
S.A. / Displ.: 17.04
Bal. / Displ.: 46.08
Disp: / Len: 246.43
Comfort Ratio: 27.17
Capsize Screening Formula: 1.81
S#: 2.08
Hull Speed: 7.03 kn
Pounds/Inch Immersion: 999.31 pounds/inch

calculation mobile

2 nd ad half width

3rd ad full width

Rig and Sail Particulars

HELP
I: 38.60 ft / 11.77 m
J: 13.60 ft / 4.15 m
P: 35.30 ft / 10.76 m
E: 13.30 ft / 4.05 m
S.A. Fore: 262.48 ft² / 24.39 m²
S.A. Main: 234.75 ft² / 21.81 m²
S.A. Total (100% Fore + Main Triangles): 497.23 ft² / 46.19 m²
S.A./Displ. (calc.): 15.69
Est. Forestay Length: 40.93 ft / 12.48 m

Sailboat Links

Designers: Carl Andersson
Builders: Vindo (Nötesund Varv AB)
Associations: Vindonet - Vindo Boats
Download Boat Record:

Notes

Also available with as a ketch.
