Sailboat Specifications

Definitions
Hull Type: Fin w/spade rudder
Rigging Type: Fractional Sloop
LOA: 43.92 ft / 13.39 m
LWL: 36.50 ft / 11.13 m
S.A. (reported): 943.00 ft² / 87.61 m²
Beam: 13.50 ft / 4.11 m
Displacement: 27,500.00 lb / 12,474 kg
Ballast: 10,750.00 lb / 4,876 kg
Max Draft: 7.50 ft / 2.29 m
Construction: FG
Ballast Type: Lead
First Built: 1989
Builder: Bristol Yachts Inc. (USA)
Designer: David Pedrick

Auxiliary Power/Tanks (orig. equip.)

Make: Westerbeke
Type: Diesel
Fuel: 70 gals / 265 L

Accomodations

Water: 165 gals / 625 L

Sailboat Calculations

Definitions
S.A. / Displ.: 16.63
Bal. / Displ.: 39.09
Disp: / Len: 252.47
Comfort Ratio: 34.28
Capsize Screening Formula: 1.79
S#: 2.11
Hull Speed: 8.10 kn
Pounds/Inch Immersion: 1,760.65 pounds/inch

calculation mobile

2 nd ad half width

3rd ad full width

Rig and Sail Particulars

HELP
I: 52.00 ft / 15.85 m
J: 15.25 ft / 4.65 m
P: 56.75 ft / 17.30 m
E: 19.25 ft / 5.87 m
S.A. Fore: 396.50 ft² / 36.84 m²
S.A. Main: 546.22 ft² / 50.75 m²
S.A. Total (100% Fore + Main Triangles): 942.72 ft² / 87.58 m²
S.A./Displ. (calc.): 16.62
Est. Forestay Length: 54.19 ft / 16.52 m
Mast Height from DWL: 64.00 ft / 19.51 m

Sailboat Links

Designers: David Pedrick
Builders: Bristol Yachts
Download Boat Record:

Notes

Also available with winged keel. Draft:5.5'/1.68m.
First promoted as BRISTOL 43.
