Sailboat Specifications

Definitions
Hull Type: Fin with rudder on skeg
Rigging Type: Masthead Sloop
LOA: 38.33 ft / 11.68 m
LWL: 30.50 ft / 9.30 m
S.A. (reported): 667.00 ft² / 61.97 m²
Beam: 12.00 ft / 3.66 m
Displacement: 17,000.00 lb / 7,711 kg
Ballast: 6,800.00 lb / 3,084 kg
Max Draft: 5.00 ft / 1.52 m
Construction: FG
Ballast Type: Lead
First Built: 1977
Last Built: 1982
# Built: 300
Builder: Morgan Yachts (USA)
Designer: Ted Brewer/Jack Corey

Auxiliary Power/Tanks (orig. equip.)

Make: Perkins
Model: 4-108
Type: Diesel
Fuel: 40 gals / 151 L

Accomodations

Water: 55 gals / 208 L

Sailboat Calculations

Definitions
S.A. / Displ.: 16.20
Bal. / Displ.: 40.00
Disp: / Len: 267.49
Comfort Ratio: 29.22
Capsize Screening Formula: 1.87
S#: 1.94
Hull Speed: 7.40 kn
Pounds/Inch Immersion: 1,307.76 pounds/inch

calculation mobile

2 nd ad half width

3rd ad full width

Rig and Sail Particulars

HELP
I: 46.00 ft / 14.02 m
J: 16.25 ft / 4.95 m
P: 40.50 ft / 12.34 m
E: 14.50 ft / 4.42 m
S.A. Fore: 373.75 ft² / 34.72 m²
S.A. Main: 293.63 ft² / 27.28 m²
S.A. Total (100% Fore + Main Triangles): 667.38 ft² / 62.00 m²
S.A./Displ. (calc.): 16.21
Est. Forestay Length: 48.79 ft / 14.87 m

Sailboat Links

Designers: Edward S. Brewer
Jack Corey
Builders: Morgan Yachts
Download Boat Record:

Notes

First introduced as the MORGAN 38 though entirely different from the model by the same name that came out in 1969.
Updated in 1981 with a taller rig, modified rudder, larger water tank, and numerous changes to the interior.
Updated again in 1983, it became the MORGAN 384. Catalina Yachts purchased Morgan Yachts in 1985, but this latter model remained in production for another year. Approximately 500 boats were built under it's varying iterations.
