Sailboat Specifications

Definitions
Hull Type: Wing Keel
Rigging Type: Masthead Sloop
LOA: 26.92 ft / 8.21 m
LWL: 22.92 ft / 6.99 m
S.A. (reported): 299.00 ft² / 27.78 m²
Beam: 9.00 ft / 2.74 m
Displacement: 5,375.00 lb / 2,438 kg
Ballast: 1,930.00 lb / 875 kg
Max Draft: 2.92 ft / 0.89 m
Construction: FG
First Built: 1985
Last Built: 1989
Builder: O'Day Corp. (USA)
Designer: Hunt & Associates

KLSC Leaderboard

KLSC Leaderboard

Accomodations

Water: 25 gals / 95 L

Sailboat Calculations

Definitions
S.A. / Displ.: 15.64
Bal. / Displ.: 35.91
Disp: / Len: 199.29
Comfort Ratio: 18.45
Capsize Screening Formula: 2.06
S#: 2.55
Hull Speed: 6.42 kn
Pounds/Inch Immersion: 737.06 pounds/inch

calculation mobile

2 nd ad half width

3rd ad full width

Rig and Sail Particulars

HELP
I: 30.83 ft / 9.40 m
J: 10.50 ft / 3.20 m
P: 26.08 ft / 7.95 m
E: 10.50 ft / 3.20 m
S.A. Fore: 161.86 ft² / 15.04 m²
S.A. Main: 136.92 ft² / 12.72 m²
S.A. Total (100% Fore + Main Triangles): 298.78 ft² / 27.76 m²
S.A./Displ. (calc.): 15.63
Est. Forestay Length: 32.57 ft / 9.93 m

Sailboat Links

Notes

An inboard engine (gas or diesel) was available as an option.
