Sailboat Specifications
DefinitionsHull Type: | Fin with rudder on skeg |
Rigging Type: | Masthead Sloop |
LOA: | 30.04 ft / 9.16 m |
LWL: | 23.00 ft / 7.01 m |
S.A. (reported): | 430.00 ft² / 39.95 m² |
Beam: | 9.00 ft / 2.74 m |
Displacement: | 8,700.00 lb / 3,946 kg |
Ballast: | 4,130.00 lb / 1,873 kg |
Max Draft: | 5.00 ft / 1.52 m |
Construction: | FG |
Ballast Type: | Lead |
First Built: | 1970 |
Last Built: | 1975 |
# Built: | 130 |
Builder: | Yankee Yachts Inc. (USA) |
Designer: | Sparkman & Stephens |
Auxiliary Power/Tanks (orig. equip.)
Make: | Universal |
Model: | Atomic 4 |
Type: | Gas |
HP: | 30 |
Accommodations
Water: | 22 gals / 83 L |
Sailboat Calculations
DefinitionsS.A. / Displ.: | 16.32 |
Bal. / Displ.: | 47.47 |
Disp: / Len: | 319.22 |
Comfort Ratio: | 28.68 |
Capsize Screening Formula: | 1.75 |
S#: | 1.56 |
Hull Speed: | 6.43 kn |
Pounds/Inch Immersion: | 739.63 pounds/inch |
Rig and Sail Particulars
HELPI: | 40.00 ft / 12.19 m |
J: | 12.75 ft / 3.89 m |
P: | 34.92 ft / 10.64 m |
E: | 10.00 ft / 3.05 m |
S.A. Fore: | 255.00 ft² / 23.69 m² |
S.A. Main: | 174.60 ft² / 16.22 m² |
S.A. Total (100% Fore + Main Triangles): | 429.60 ft² / 39.91 m² |
S.A./Displ. (calc.): | 16.30 |
Est. Forestay Length: | 41.98 ft / 12.80 m |
Sailboat Links
Designers: | Sparkman & Stephens |
Builders: | Yankee Yachts Inc. (USA) |
Related Sailboats: | YANKEE 30 MKIII (3/4 TON) |
Download Boat Record: |
Notes
After Yankee Yachts went out of business in 1975, a few boats were built by Heritage Boat Works (OR) and Vashon Island Boat Works (WA),USA.
From this latter builder also came the VASHON ISLAND 30 or VASHON 30, a Pilot House cruiser that appears to share the same hull.
The MK I, II, and III, were differentiated primarily by incrementally taller rigs as well as a few details in the interior layout.
(Hulls after #98 are designated MK II).
The MK III, has an additional 1000 lbs. of internal ballast. (Rig dimension as well as other details are not always consistent within a particular version.)
Available engines:
Universal Atomic 4 (gas)
Albin 2-cyl Diesel
Bukh 2-cyl Diesel
The S&S 30, built by Swarbrick Brothers of Australia is based on the same design (S&S No. 1999-C1).
